Actual Product May Vary

Rough Country Suspension

08-10 Ford SD 4WD 8in Lift Kit 4-Link M1

$1,949.95
$1,789.95
(You save $160.00 )
As low as $45.39/mo with Learn More

Description

08-10 Ford SD 4WD 8in Lift Kit 4-Link M1 Actual Product May Vary

Product Info

Rough Country 8 Inch Lift Kit - 4 Link - M1 - Ford Super Duty 4WD (2008-2010)

Compliment your 08-10 Ford F-250/350's aggressive, good looks with Rough Country's 4-Link Suspension Lift System. Rough Country's 8-inch Lift Kit was engineered to retain the F-250/350's impressive factory specs while bumping up performance and durability where it's needed most. The result is an aggressive, lifted beast with a mean profile and balanced on and off-road ride quality.

When changing a vehicle's suspension, the key to preserving ride quality is in keeping the geometry of all suspension components as close to their factory angles as possible. Rough Country's 4-Link Suspension Lift System features a set of ultra-durable radius arm drop brackets, precision fit to bolt right into the factory mounts for an easier install and a more factory-like angle.

This all-inclusive kit also features an adjustable lower control arms at the axle to allow caster adjustment as well as a track bar relocation bracket and a drop pitman arm. A full set of N3 Shocks provide a truly balanced ride quality for on and off-road use - perfect for daily drivers. This kit also ships with a set of durable, lifted coil springs and brake line relocation brackets.

This innovative kit design features a 100% bolt-on installation process that is lightning fast compared to other kits this size. Save time and money with no need for cutting, drilling, or other complicated procedures. Rough Country's Rough Country's 4-Link Suspension Lift System is backed by our Lifetime Replacement Warranty.

  • Easy bolt-on installation
  • Increased ground clearance
  • Levels the front with the rear of the vehicle
  • Radius arm drop brackets allow for properly set caster. Proper caster is crucial to maintaining factory handling and driveability.
  • Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.
  • Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
  • Specially designed anti-axle wrap rear blocks maintain stock ride quality while eliminating common lift block problems.

Front Components:

  • Lifted coil springs
  • Fixed upper control arms
  • Adjustable lower control arms
  • Radius arm drop brackets
  • Extended sway-bar links
  • Track bar drop bracket
  • Stabilizer relocation brackets
  • Pitman arm
  • Stainless steel braided brake lines
  • Bumpstop spacers
  • Hardware

Install Time: 8 - 10 hours

Rear Components:

  • 8 in fabricated anti-wrap lift blocks
  • Carrier bearing drop bracket
  • U-bolts
  • Hardware

Tire, Wheel, and Offset Info:

  • 37x13.50R17:17x9:8x170:-12:-
  • 37x13.50R17:17x9:8x170:+0:-
  • 37x13.50R17:17x9:8x170:+1:-
  • 37x13.50R18:18x9:8x170:-12:-
  • 37x13.50R18:18x9:8x170:+0:-
  • 37x13.50R18:18x9:8x170:+1:-
  • 37x13.50R20:20x9:8x170:-12:-
  • 37x13.50R20:20x9:8x170:+0:-
  • 37x13.50R20:20x9:8x170:+1:-
  • 37x12.50R20:20x10:8x170:-25:-
  • 37x12.50R20:20x10:8x170:-24:-
  • 37x12.50R20:20x10:8x170:-19:-
  • 37x12.50R20:20x10:8x170:-18:-
  • 37x12.50R20:20x12:8x170:-44:Trimming Required
  • 37x12.50R22:22x10:8x170:-25:-
  • 37x12.50R22:22x10:8x170:-24:-
  • 37x12.50R22:22x10:8x170:-19:-
  • 37x12.50R22:22x10:8x170:-18:-
  • 37x12.50R22:22x12:8x170:-44:Trimming Required

Specs

  • SKU: HEC 59240
  • UPC: 840269918261
  • Weight: 123.45 LBS
  • Product Sub Category: Lift Kits
  • Data Fitment Make: Ford
  • Data Fitment Model: F250, F350
  • Data Fitment Year: 2008, 2009, 2010
  • Data Default Qt: 1
  • Data Product Type: Mom Class Bolt-on
  • Data Shipping Group: HEC shipping
  • Kit Height: 8

Fitment

Make Model Sub-model Years
FordF-250 Super DutyCabela's2009,2010
FordF-250 Super DutyFX42008,2009
FordF-250 Super DutyHarley-Davidson Edition2008,2009,2010
FordF-250 Super DutyKing Ranch2008,2009,2010
FordF-250 Super DutyLariat2008,2009,2010
FordF-250 Super DutyXL2008,2009,2010
FordF-250 Super DutyXLT2008,2009,2010
FordF-350 Super DutyCabela's2009,2010
FordF-350 Super DutyFX42008,2009
FordF-350 Super DutyHarley-Davidson Edition2008,2009,2010
FordF-350 Super DutyKing Ranch2008,2009,2010
FordF-350 Super DutyLariat2008,2009,2010
FordF-350 Super DutyXL2008,2009,2010
FordF-350 Super DutyXLT2008,2009,2010
