14-18 Ram 2500 DSL 6.5in Kit w/Shocks - Zone Off-Road Products

The picture shown is shown with optional black nitro shocks. This kit includes shocks.

This Zone 6.5" system for the 14-18 Dodge 2500 utilizes heavy duty radius arm brackets and progressive rate front coil springs. The supplied drop pitman arm, extended bump stops, track bar relocation bracket, sway bar drops and brake line relocation adjust all the rest of the critical components and angles. The system coupled Nitro shocks provides a great handling, smooth ride suspension system. The rear of the truck is lifted with a replacement coil spring to provide a level stance.

For those looking to use their 4wd on the road at speed we highly recommend adding the optional t-case indexing kit to improve the front driveline angles. These two kits (for the 6-bolt and 8-bolt T-cases) come with a t-case indexing ring, front driveshaft spacer and heavy-duty replacement transmission crossmember. The t-case indexing kits can be installed when the lift is installed or anytime after if the need arises.

• Front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit. Models with a 6 bolt transfer case use part # D5613. Models with an 8 bolt transfer case use part #D5813.
• Vehicles equipped with a two piece drive shaft and a carrier bearing require bearing drop kit D5405.
• Not designed for factory rear airbag suspension models.
• Fits trucks equipped with the diesel engines.

Quick Specs:

• Front Lift Height: 6.5"
• Front Lift Method: Progressive Coil Springs and Radius Arm Drop Brackets
• Rear Lift Height: 4.5"
• Rear Lift Method: Coil Springs
• Difficulty Level 1-5: 3
• Max Tire Size: 35 X 12.50 w/ 4.5" Backside Wheel
• Max Tire Size: 37 X 12.50 w/ 5.625" Backside Wheel
