23 Ford F150 4WD 3in Lift Kit

Improved Ground Clearance and Ride Quality. Rough Country's 3-inch Bolt-On Kit offers easy installation and aggressive good looks at an incredible value. Take your truck to new heights with this excellent option for your ninth-generation Ford F-150.

High-Quality Construction. This kit features a set of high-quality, Forged 6082-6 Aluminum Upper Control Arms designed to make alignment adjustments easier and Clevite rubber bushings for enhanced durability. These arms are designed to promote a factory-like geometry by keeping the ball joint at optimum angles after lifting. This design allows for an improved, greater range of motion from the ball-joint, with less stress, wear and tear. Also included are a set of rear blocks to provide lift height in the rear. Once installed, this kit gives your truck plenty of ride height for up to 34in tires while offering a clean, level look from front to rear. Retain your stock wheels with this kit when you use Rough Country's 0.25-inch wheel spacer.

Installation and Warranty. This all-inclusive kit comes with everything you need, and installation is a piece of cake compared to other kits on the market! Featuring a 100% bolt-on installation process that requires zero cutting or drilling, this kit can be installed using common tools in a home garage, and allows the truck to be returned to stock at any time if so desired. You also get peace of mind knowing that your purchase comes with a limited lifetime replacement warranty for manufacturer defects. With Rough Country's industry-leading warranty, you can be sure that your Rough Country lift kit is protected from structural and workmanship damage after the date of purchase.

Features

• Easy Bolt-On installation. No Cutting or Drilling required!
• Includes New tubular upper control arms.
• Control arms keep ball joints at optimum angles for less wear and tear.
• Control arms include Clevite rubber bushings for enhanced durability.
• Increased ground clearance.
• Levels the front and rear of the truck.
• Can be returned to stock.

Optional N3 Loaded Struts

• Includes pre-loaded coil.
• Maintains smooth, factory-like ride.
• Engineered for lifted applications.
• Infinitely Variable Damping.
• Leak-proof piston seal.
• Massive 1 3/8in Bore.
• Silver powder coat finish.
• 3-year Manufacturer's Warranty.

Optional M1 Monotube Struts

• 2-inch seamless extruded tube.
• 46mm digressive piston.
• Digressive valving.
• Fast heat dissipation.
• Fade-free performance.
• Natural rubber bushings.
• Zinc plated aluminum body.
• 3-year Manufacturer's Warranty.

Optional Vertex Coilovers

• 8-Stage Adjustable Damping.
• Monotube Design.
• Nitrogen-charged.
• Massive 2.5in Piston.
• 22mm Chrome-Hardened Piston Rod.
• 3-Stage Seal System.
• Heat-Treated, Alloy Bearing.
• Honed Steel Body.
• 3-year Manufacturer's Warranty.

Notes

• Retain your factory wheels by using our 0.25-inch wheel spacers SKU: 1065.
• Does NOT fit regular/standard cab models.
• Does NOT fit models equipped with CCD system.
• SKU: 41430 does NOT work on models with stock ride height over 22in (measured from center of wheel to the bottom of the fender).
• Spacer kit '41430' does NOT fit on trucks with FX4, Snow Prep, and other off-road packages that modify front strut assemblies will likely measure over 22in and will not work with this kit.

Manufacturer: Rough Country

Product: 3 Inch Lift Kit - Ford F-150 4WD (2023)

Additional Features

• Easy Bolt-On installation
• Maintains smooth
• No Cutting or Drilling required!
• Includes New tubular upper control arms
• Control arms keep ball joints at optimum angles for less wear and tear
• Control arms include durable rubber bushings for enhanced durability
• Increased ground clearance
• Levels the front and rear of the truck
• Can be returned to stock
• Optional N3 Loaded Struts Includes pre-loaded coil

Installation Time: 5-6 hours

Front Components:

• (2) Upper control arms
• (2) Strut spacers

Install Time: 5-6 hours

Rear Components:

• (2) Lift Blocks
• (4) U-bolts
• Hardware

Tire, Wheel, and Offset Info:

• 275/65R20: Factory 20: 6x135: - : 0.25 Spacer
• 295/70R18: 18x9: 6x135: +18: -
• 305/55R20: 20x9: 6x135: -12: -
• 295/60R20: 20x9: 6x135: -12: -
• 305/55R20: 20x9: 6x135: +0: -
• 295/60R20: 20x9: 6x135: +0: -
• 305/55R20: 20x9: 6x135: +1: -
• 295/60R20: 20x9: 6x135: +1: -
• 295/60R20: 20x9: 6x135: +18: -
• 305/55R20: 20x9: 6x135: +20: -
• 295/60R20: 20x9: 6x135: +20: -
• 305/55R20: 20x10: 6x135: -25: -
• 295/60R20: 20x10: 6x135: -25: Minor Trimming
• 305/55R20: 20x10: 6x135: -24: -
• 295/60R20: 20x10: 6x135: -24: Minor Trimming
• 305/55R20: 20x10: 6x135: -19: -
• 295/60R20: 20x10: 6x135: -19: Minor Trimming
• 305/55R20: 20x10: 6x135: -18: -
• 295/60R20: 20x10: 6x135: -18: Minor Trimming
• 305/45R22: 22x10: 6x135: -25: -
• 305/45R22: 22x10: 6x135: -24: -
• 305/45R22: 22x10: 6x135: -19: -
• 305/45R22: 22x10: 6x135: -18: -

Title: Rough Country 3 Inch Lift Kit - Ford F-150 4WD (2023)
