19-21 Ram 3500 5in Radius Arm Susp Lift Kit w/AISIN Trans

Product Features:

• 5.0 Inch Dodge Radius Arm Suspension Lift Kit w/ AISIN Transmission (19-20 Ram 3500 4WD Diesel)
• Increased ground clearance
• Track bar bracket keeps the front axle properly centered
• Radius Arms offer a more factory-like angle and feature a durable, Clevite Rubber Bushings for maximum vibration absorption
• Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use

Notes:

• Requires removal of Transfer case for clocking ring install for correct front driveline geometry
• Does Not fit Power Wagon models
• Does Not fit air ride models
• Rear wheels may require additional dually wheel spacers to run 12.50in wide tire
• Only fits Diesel models
• Requires minor cutting
• On vehicles equipped with a two-piece driveshaft and carrier bearing as on the Mega Cab, there is the potential for take-off vibration, depending on the severity, this can be corrected with shimming down the carrier bearing

Manufacturer/Brand:

Rough Country 37830 5 Inch Lift Kit

Installation Time:

6-8 hours

Front Components:

Lifted Coil springs, Radius arms, Track Bar bracket, Transmission crossmember, clocking ring, Sway-bar brackets, Pitman arm, Carrier bearing shims, Hardware

Rear Components:

Rear lift blocks, U-bolts, Track bar bracket, Sway-bar links, Hardware

Tire, Wheel, and Offset Info:

37x12.50R17:17x8.5:8x6.5/8x165.1:+0:-; 37x12.50R17:17x8.5:8x6.5/8x165.1:+1:-; 37x12.50R17:17x9:8x6.5/8x165.1:-12:-; 37x12.50R17:17x9:8x6.5/8x165.1:+0:-; 37x12.50R17:17x9:8x6.5/8x165.1:+1:-; 37x12.50R18:18x8.5:8x6.5/8x165.1:+0:-; 37x12.50R18:18x8.5:8x6.5/8x165.1:+1:-; 37x12.50R18:18x9:8x6.5/8x165.1:-12:-; 37x12.50R18:18x9:8x6.5/8x165.1:+0:-; 37x12.50R18:18x9:8x6.5/8x165.1:+1:-; 37x12.50R18:18x10:8x6.5/8x165.1:-25:Minor Trimming; 37x12.50R18:18x10:8x6.5/8x165.1:-24:Minor Trimming; 37x12.50R18:18x10:8x6.5/8x165.1:-19:Minor Trimming; 37x12.50R18:18x10:8x6.5/8x165.1:-18:Minor Trimming; 37x12.50R20:20x9:8x6.5/8x165.1:-12:-; 37x12.50R20:20x9:8x6.5/8x165.1:+0:-; 37x12.50R20:20x9:8x6.5/8x165.1:+1:-; 37x12.50R20:20x10:8x6.5/8x165.1:-25:Minor Trimming; 37x12.50R20:20x10:8x6.5/8x165.1:-24:Minor Trimming; 37x12.50R20:20x10:8x6.5/8x165.1:-19:Minor Trimming; 37x12.50R20:20x10:8x6.5/8x165.1:-18:Minor Trimming

Title:

Rough Country 5 Inch Lift Kit - Diesel - AISIN - Ram 3500 4WD (2019-2023)
